IND 20T

Our wide range of IND 20T In-Car Monitors can be configured for different sizes according to your needs. Low cost and high quality, our preferred in-car monitors offer multiple options such as different signal, resolution, brightness, touch.

Other News

IND 10T

IND 30T

FANLESS DESIGN

HDMI

RJ 45

USB 2.0

Technical Specifications

OPERATING SYSTEM	Embedded 8, Embedded Standard 7 E
PROCESSOR	Intel® Core™ İ5-5350U Dual Core, 1.8 GHz
CHIPSET	SoC
RAM	2 x DDR3 SO-DIMM Slot, 4 GB (System max. 16 GB)
SCREEN	1 x VGA, 1 x HDMI (VGA:2560 x 1600)(HDMI:3840 x 2160)
STORAGE	Hard Drive 1 x 2.5 "SATA 6Gb / s HDD / SSD Driver Slot 1 x mSATA (SATA 6Gb/s) (SD 2.0, Max 32GB supported)
EXTENSION	1 x Full-size PCIe Mini (reserved for WWAN or mSATA) 1 x Half-size PCIe Mini (reserved for WLAN)
AUDIO	1 x Audio Input, 1 x Audio Input
NETWORK	WLAN PCIe Mini Wi-Fi 802.11b / g / n (Optional) Bluetooth 2.1 (With WWAN module if wanted) PCIe Mini Wi-Fi 802.11b/g/n (optional) GPS Aerial: 1 x 3G, 1 x BT, 1 x Wi-Fi 4 x RJ-45 / 2 x DB-9 RS-232/422/485 4 x DB-9 RS-232 (optional)
PORTS	2x USB 3.0 / 2x USB 2.0 SIM Card Slot I / O 8-bit digital I / O (4-bit input, 4-bit output)
KEYBOARD & MOUSE	Optional
POWER	Consume: 12 V @ 3.2 A
CASE	Alluminium Alloy
SIZE	256 x 64x 152mm
CERTIFICATES	EMC CE / FCC / E-Mark
OTHER	MIL-STD-810F (with SSD)
GUARANTEE	2 Years

All Specifications

Overview
All transportation vehicles, buses, trams, metrobuses, subway cars, such as wagons, information boards can be used. Our in-car computers, which serve many purposes, are designed to work without fans and are specially designed to prevent dirt and dust. Since they are customizable computers, the desired splicing and stickers can also be made in the components.
